ACA: 40.00 A, 600.0 A /1.5% ± 5 digit
ACA: 40.00 A, 600.0 A /1.5% ± 5 digit)
ACV: 600.0 V /1.5% ± 5 digit
DCV: 600.0 V /1% ± 4 digit
R: 400.0 Ω, 4000 Ω /1% ± 5 digit
Continuity:≤ 30 Ω
Digital Display:6000 count resolution
Power Source: Three AAA IEC LR03 batteries
Clamp Opening Size:1. 45 in (37 mm)
Dimensions (L x W x H): 162.4 mm x 58.25 mm x 30.5 mm
Weight: 384 g
Include:Test Leads, Soft Carrying Case, Three AAA batteries (Installed),User Manual
Details
| General Specifications |
| Digital Display |
|
| Low Battery Indication |
| |
Displays a signal when the batteries are below their required voltage |
|
| Power Source |
| |
Three AAA IEC LR03 batteries |
|
| Clamp Opening Size |
|
| Jaw Diameter |
|
| Dimensions (L x W x H) |
| |
6.39 in x 2.29 in x 1.20 in |
| |
(162.4 mm x 58.25 mm x 30.5 mm) |
|
| Weight |
| |
approximately 13.5 oz (384 g) (batteries included) |
|
| Auto Range |
|
| Safety |
| |
CE |
| |
EN/IEC 61010-1 and IEC 61010-2-032 |
| |
Measurement Category: 600V CAT III |
|
| 317 Electrical Specifications |
| Current AC |
| Range |
40.00 A, 600.0 A |
| Resolution |
0.01 A, 0.1 A |
| Accuracy |
1.6% ± 6 digit (50-60 Hz) {40 A} |
| |
2.5% ± 8 digit (60-500 Hz) {40 A} |
| |
1.5% ± 5 digit (50-60 Hz) {600 A} |
| |
2.5% ± 5 digit (60-500 Hz) {600 A} |
| Crest Factor add 2% into spec for CF > 2 |
3.0 Max @ 500 A, 2.5 Max @ 600 A |
| AC response |
rms |
|
| Current DC |
| Range |
40.00 A, 600.0 A |
| Resolution |
0.01 A, 0.1 A |
| Accuracy |
1.6% ± 6 digit (40 A) |
| |
1.5% ± 5 digit (600 A) |
|
| Voltage AC |
| Range |
600.0 V |
| Resolution |
0.1 V |
| Accuracy |
1.5% ± 5 digit (20-500Hz) |
| AC response |
rms |
|
| Voltage DC |
| Range |
600.0 V |
| Resolution |
0.1 V |
| Accuracy |
1% ± 4 digit |
|
| Resistance |
| Range |
400.0 Ω, 4000 Ω |
| Resolution |
0.1 Ω, 1 Ω |
| Accuracy |
1% ± 5 digit |
|
| Continuity |
|
| Inrush |
|
| Frequency |
| Range |
N/A |
| Accuracy |
N/A |
| Trigger Level |
N/A |
|
| 319 Electrical Specifications |
| Current AC |
| Range |
40.00 A, 600.0 A, 1000 A |
| Resolution |
0.01 A, 0.1 A, 1 A |
| Accuracy |
1.6% ± 6 digit (50-60 Hz) {40 A} |
| |
2.5% ± 8 digit (60-500 Hz) {40 A} |
| |
1.5% ± 5 digit (50-60 Hz) {600/1000 A} |
| |
2.5% ± 5 digit (60-500 Hz) {600/1000 A} |
| Crest Factor add 2% into spec for CF > 2 |
3.0 Max @ 500 A, 2.5 Max @ 600 A, 1.4 Max @ 1000 A |
| AC response |
rms |
|
| Current DC |
| Range |
40.00 A, 600.0 A, 1000 A |
| Resolution |
0.01 A, 0.1 A, 1 A |
| Accuracy |
1.6% ± 6 digit (40 A) |
| |
1.5% ± 5 digit (600/1000 A) |
|
| Voltage AC |
| Range |
600.0 V |
| Resolution |
0.1 V |
| Accuracy |
1.5% ± 5 digit (20-500Hz) |
| AC response |
rms |
|
| Voltage DC |
| Range |
600.0 V |
| Resolution |
0.1 V |
| Accuracy |
1% ± 4 digit |
|
| Resistance |
| Range |
400.0 Ω |
| |
4000 Ω |
| Resolution |
0.1 Ω |
| |
1 Ω |
| Accuracy |
1% ± 5 digit |
|
| Continuity |
|
| Inrush |
|
| Frequency |
| Range |
5.0 - 500.0 Hz |
| Accuracy |
0.5% ± 5 digit |
| Trigger Level |
10 - 100 Hz ≥ 5 A, 5 - 10 Hz, 100 - 500 Hz ≥ 10 A |
|
